DIGITAL MULTIMETER
Brand : DV
Type : DT82040
Parameter Measure :
– DCV : 400m-4-40-400-600V (±0.5%)
– ACV : 400m-4-40-400-600V (±1%)
– DCA : 40u-400u-4m-40m-400m-10A (±1.8%)
– ACA : 200-2000-20k-200k-2000kΩ (±2.0%)
– OHM : 400-4k-40k-400k-4M-40MΩ (±1.0%)
– Cap : 40n-400n-4u-40u-400uF (±4.0%)
– Frequency : 5-5MHz (±3.0%)
– Temperature : -20°C˶1000°C 4°F˶1832°F (±2.0%)
– Duty Cycle : 0.1%˶99.9% (±1.0%)
Feature :
– Diode test
– Continuity buzzer
– Transistor test
– Auto power off
– Data hold
– Auto range
Power supply : 1.5V x 2battery
Size : 145x70x35mm
Digital multimeter is designed to measure various electrical parameters in circuits using digital readings.
DV digital multimeter offer a wide range of parameters and high accuracy at an affordable price.
DV Electrical Product – Quality You Can Trust
| Datasheet |  |
|---|---|
| DIGITAL AUTO RANGE MULTIMETER DT82040 |
